| Code |
Part Name |
|
| 1 |
Frame |
|
| 2 |
Engine |
|
| 3 |
Rear Fork (Left or Right) |
|
| 4 |
Radiator |
|
| 5 |
Connecting Board (Upper or Lower) |
|
| 6 |
Front Shock Absorber (Left or Right) |
|
| 7 |
Direction Handle |
|
| 8 |
Direction Handle Button |
|
| 9 |
Front Disk Brake Calipers (Left or Right) |
|
| 10 |
Front or Rear Wheel Rim |
|
| 11 |
Front or Rear Tyre (with air valve) |
|
| 12 |
Front or Rear Brake Disc |
|
| 13 |
Tank( fairing ) |
|
| 14 |
Seat Bracket |
|
| 15 |
Muffler (exhaust) |
|
| 16 |
Pump |
|
| 17 |
Windshield |
|
| 18 |
Front Cover |
|
| 19 |
Left Front Fairing |
|
| 20 |
Right Front Fairing |
|
| Front Mudguard |
|
| 21 |
Heating Pane |
|
| 22 |
Rear Seat Fairing (Left or Right) |
|
| 23 |
Rear Mudguard |
|
| 24 |
Filter (with clip) |
|
| 25 |
Kettle (with cap) |
|
| 26 |
Seat |
|
| 27 |
Chain Sprocket Gear |
|
| 28 |
Pump Wheel |
|
| 29 |
Chain |
|
| 30 |
Pump Belt |
|
| 31 |
Rear Disk Brake Calipers |
|
| 32 |
Handle Rubber Cover (Left or Right) |
|
| 33 |
Rocker Combination (Left or Right) |
|
| 34 |
Throttle Fixer |
|
| 35 |
Front Brake Handle |
|
| 36 |
Front Brake Cable |
|
| 37 |
Rear Brake Cable |
|
| 38 |
Pipe |
|
| 39 |
Nozzle Tip |
|
| 40 |
Oil Pipe (with clip) |
|
| 41 |
Foot Rest |
|
| 42 |
Pedal Holding Bracket (Left or Right) |
|
| 43 |
Muffler Spring |
|
| 44 |
Muffler Clip |
|
| 45 |
Jack Piece |
|
| 46 |
Jack |
|
| 47 |
Front or Rear Wheel Bearing |
|
| 48 |
Direction Cylinder Bearing |
|
| 49 |
Connecting Piece |
|
| 50 |
Oil Pipe Fixer |
|
| 51 |
Cut Out Switch |
|
| 52 |
Front or Rear Wheel Axle |
|
| 53 |
Connecting Board Shaft (up or down) |
|
| 54 |
Front Wheel Axle Cover (Left or Right) |
|
| 55 |
Front Wheel Axle Cover (middle) |
|
| 56 |
Rear Axle Cover (Right) |
|
| 57 |
Rear Axle Cover (middle) |
|
| 58 |
Rear Axle Cover (Left) |
|
| 59 |
Pump Wheel Axle Cover |
|
| 60 |
Muffler Axle Cover |
|
| 61 |
Front Fairing Bracket |
|
| 62 |
Front Shock Absorber Adhesive |
|
| 63 |
Fixing Bracket Behind the Tank |
|
| 64 |
Tank Adhesive |
|
| 65 |
Clip |
|
| 66 |
Engine Fixing Axle Cover |
|
A1 |
Petrol Cap |
