NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10001S |
Pullstarter |
1 |
2 |
MD03-10002L |
Pullstart claw clog |
1 |
3 |
MD03-10003X |
Ignition coil |
1 |
4 |
MD03-10004L |
Flywheel |
1 |
5 |
MD03-10005L |
Crankcase R |
1 |
6 |
MD03-10006L |
Spark plug |
1 |
7 |
MD03-10007L |
Cylinder head |
1 |
8 |
GB70-85 |
bolt M6×20 |
4 |
9 |
MD03-10009Z |
Cylinder head gasket |
1 |
10 |
MD03-10010Z |
Crankcase gasket |
1 |
11 |
MD03-10011L |
Crankcase L |
1 |
12 |
GB70-85 |
Screw M6×60 |
4 |
13 |
MD03-10013L |
Clutch |
1 |
14 |
MD03-10014L |
clutch housing |
1 |
15 |
GB70-85 |
Screw M6×20 |
2 |
16 |
GB848-85 |
Washer φ6 |
6 |
17 |
GB70-85 |
Screw M6×20 |
6 |
18 |
MD03-10018S |
Driving sprocket cover |
1 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10019T |
Crank shaft |
1 |
2 |
MD03-10020G |
Piston pin circle |
2 |
3 |
MD03-10021L |
Piston |
1 |
4 |
MD03-10022H |
Piston ring |
2 |
5 |
MD03-10023G |
Needle bearing |
1 |
6 |
MD03-10024G |
Piston pin |
1 |
7 |
MD03-10025G |
Semicircular key |
2 |
8 |
MD03-10026Y |
Oil sealφ25×φ15×7 |
2 |
9 |
MD03-10027G |
Bearing 6202P6 |
2 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10028Z |
Inlet valve gasket |
1 |
2 |
MD03-10029T |
Inlet valve |
1 |
3 |
MD03-10030Z |
Intake pipe gasket |
1 |
4 |
MD03-10031X |
Intake pipe |
1 |
5 |
MD03-10032Z |
Carburetor gasket |
1 |
6 |
MD03-10033L |
Carburetor |
1 |
7 |
MD03-10034S |
Air filter collar |
1 |
8 |
MD03-10035T |
Air filter hoop |
1 |
9 |
MD03-10036X |
Air filter |
1 |
10 |
GB70-85 |
Screw M6×20 |
4 |
11 |
GB70-85 |
Screw M6×60 |
2 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10039L |
engine complete |
1 |
2 |
MD03-10040N |
chain |
1 |
3 |
MD03-10041G |
throttle cable 560x680 |
1 |
4 |
MD03-10042T |
engine fixing bracket |
1 |
5 |
MD03-10043L |
sprocket cover |
1 |
6 |
GB889-86 |
nut M6 |
1 |
7 |
GB848-85 |
nut φ6 |
2 |
8 |
GB70-85 |
bolt M6x20 |
1 |
9 |
GB848-85 |
bushφ5 |
2 |
10 |
GB70-85 |
bolt M5x16 |
2 |
11 |
GB70-85 |
bolt M6x16 |
2 |
12 |
GB848-85 |
bushφ6 |
2 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10051T |
handlebar |
1 |
2 |
MD03-10052X |
left handle grip |
1 |
3 |
MD03-10053T |
left brake lever |
1 |
4 |
MD03-10054T |
stop switch |
1 |
5 |
MD03-10055T |
right brake lever |
1 |
6 |
MD03-10056X |
throttle handle |
1 |
7 |
MD03-10057G |
rear brake cable |
1 |
8 |
MD03-10058L |
rear brake caliper |
1 |
9 |
MD03-10059L |
front brake caliper |
1 |
10 |
MD03-10060G |
front brake cable |
1 |
11 |
GB848-85 |
Bush φ6 |
4 |
12 |
GB70-85 |
bolt M6x16 |
4 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10063T |
main frame |
1 |
2 |
MD03-10064T |
rear swing arm |
1 |
3 |
MD03-10065T |
chain guard |
1 |
4 |
MD03-10066G |
rear swing arm shaft |
1 |
5 |
MD03-10067T |
rear swing arm shaft spacer |
1 |
6 |
MD03-10068T |
chain adjuster |
2 |
7 |
GB848-85 |
Bush φ10 |
1 |
8 |
GB889-86 |
Nut M10 |
1 |
9 |
MD03-10071T |
tensioner bracket |
1 |
10 |
MD03-10072T |
bearing 609 |
1 |
11 |
GB70-85 |
spring |
1 |
12 |
GB848-85 |
clip D=25 |
1 |
13 |
MD03-10075G |
sproket 6 teeth |
1 |
14 |
GB848-85 |
spacer φ12Xφ16X4 |
1 |
15 |
GB848-85 |
Nut M8 |
1 |
16 |
GB70-85 |
Bolt M6x12 |
2 |
17 |
MD03-10079T |
Chain tensioner assy. Complete |
1 |
|
|
 |
|
NO |
PART NO |
PART NAME |
Qty |
1 |
MD03-10080T |
Front brake caliper fixing bracket |
1 |
2 |
MD03-10081L |
fork foot |
2 |
3 |
MD03-10082L |
front fork |
2 |
4 |
MD03-10083X |
front fork up cover |
2 |
5 |
GB889-86 |
nut M6 |
4 |
6 |
GB70-85 |
bolt M6x45 |
4 |
7 |
GB848-85 |
washer φ6 |
2 |
8 |
MD03-10087T |
bracket |
2 |
9 |
GB70-85 |
bolt M6x16 |
2 |
10 |
GB889-86 |
nut M10 |
1 |
11 |
MD03-10090G |
steering shaft M10x140 |
1 |
12 |
GB848-85 |
washer φ10 |
3 |
13 |
MD03-10092G |
bearing 6200 |
2 |
14 |
MD03-10093T |
sleeve |
1 |
15 |
MD03-10094L |
lower splintage |
1 |
16 |
MD03-10095L |
upper splintage |
1 |
17 |
GB70-85 |
bolt M10x35 |
2 |
18 |
MD03-10097L |
hanldlebar holder |
2 |
19 |
MD03-10098L |
handlebar clamp |
2 |
20 |
GB70-85 |
bolt M8x25 |
4 |
21 |
MD03-10100L |
Complete fork assy. |
1set |
22 |
MD03-10101L |
Complete holder and clamp assy |
1set |
|
|
